Analog Converter CHFQ-04-M

Technical Specifications

• Operating Voltage: DC12V / DC24V
• Input Load: Supports 1 × 350Ω sensor
• Compatible Sensitivity Range: 1.0~2.0mV/V
• Output Signal: 0-5V, 0-10V, 4-20mA, 4-12-20mA
• Operating Temperature Range: -20~70℃
• Excitation Voltage: 5V / 9V
• Power Consumption: 0.1W
• Operating Humidity: 10%RH – 90%RH (non-condensing)
• Overall Accuracy: 0.1%F·S
• Wiring Diagram: (Specify details)
